XU型溝蓋板

XU groove cover plate

適用于大多數普通混泥土砌制的無沿口溝，采用U型的溝蓋非常簡單與節約，不需要特殊的溝沿口，當荷載T-6,T-14時，溝上建議埋設角鋼。當需要過車時，該類型的溝蓋僅適用于側溝（車行方向平行于溝的方向）。適用于大多數普通混泥土砌制的無沿口溝，采用U型的溝蓋非常簡單與節約，不需要特殊的溝沿口。當荷載T-6,T-14時，溝上建議埋設角鋼。當需要過車時，該類型的溝蓋僅適用于側溝（車行方向平行于溝的方向）。代號說明：

Suitable for most ordinary concrete masonry ditch without edges, using a U-shaped ditch cover is very simple and economical, without the need for special ditch edges. When the load is T-6, T-14, it is recommended to bury angle steel on the ditch. When passing through a vehicle, this type of ditch cover is only suitable for side ditches (the direction of the vehicle is parallel to the direction of the ditch). Suitable for most ordinary concrete masonry ditch without edges, using a U-shaped ditch cover is very simple and economical, without the need for special ditch edges. When the loads are T-6 and T-14, it is recommended to bury angle steel in the trench. When passing through a vehicle, this type of ditch cover is only suitable for side ditches (the direction of the vehicle is parallel to the direction of the ditch). Code Description:

XT型溝蓋板

XT type ditch cover plate

適用于帶支座沿口的溝上，沿口通常用角鋼砌護。當作為橫斷溝蓋使用時（車行方向與 溝的方向垂直），考慮到蓋板受沖擊挑起的危險，應采用螺栓固定式溝蓋或焊接于角鋼砌護上，鋼格板溝蓋防腐采用熱浸鍍鋅。

Suitable for ditches with supports along the mouth, usually protected by angle steel. When used as a transverse trench cover (perpendicular to the direction of the vehicle), considering the danger of the cover being lifted by impact, bolt fixed trench covers or welded to angle steel masonry should be used. The steel grating trench cover should be hot-dip galvanized for corrosion prevention.

XM型溝蓋板

XM type ditch cover plate

道路園區等市政設施的雨水井沉沙井下水進污水井等給排水井孔或氣孔人孔的蓋板，均可采用該類型蓋板。

This type of cover plate can be used for the rainwater well, sedimentation well, sewage inlet well, drainage well, or air vent manhole of municipal facilities such as road parks.

XG溝蓋板

XG ditch cover plate

適用于支座沿口較深的溝上，當與混凝土蓋井板并排使用時，可與混泥土溝蓋板上表面平齊；當作為橫斷溝蓋使用時（車行方向與溝蓋的方向垂直），能有效防止蓋板受沖擊挑起的危險。鋼格板溝蓋防腐采用熱浸鋅。

Suitable for deep grooves along the support edge, when used side by side with concrete manhole covers, it can be flush with the surface of the concrete trench cover plate; When used as a transverse trench cover (with the direction of the vehicle perpendicular to the direction of the trench cover), it can effectively prevent the danger of the cover being lifted by impact. The steel grating trench cover is coated with hot-dip zinc for corrosion prevention.

鑄鐵溝蓋板

Cast iron trench cover plate

材質：灰濤鐵件 球墨鑄鐵件

Material: Gray Tao iron parts, ductile iron parts

主要用途：用于檢查井排水井排水溝蓋板

Main use: Used for inspection wells, drainage wells, drainage ditch cover plates

鑄鐵蓋板產品會出現氣孔裂紋等質量缺陷，并且不能補焊。

Cast iron cover plate products may have quality defects such as porosity and cracks, and cannot be repaired by welding.

鑄鐵蓋板韌性小脆性較大，有斷裂危險。

Cast iron cover plates have low toughness and high brittleness, posing a risk of fracture.

在天氣寒冷時，鑄鐵蓋板表面結冰，防滑效果差。

When the weather is cold, the surface of the cast iron cover plate freezes, and the anti slip effect is poor.

鋼格柵溝蓋板

Steel grating trench cover plate

材質：低合金碳素鋼

Material: Low alloy carbon steel

主要用途：用于檢查井排水井排水溝采光井等的蓋板。

Main use: Used as a cover plate for inspection wells, drainage wells, drainage ditches, lighting wells, etc.
